Name | Value | Description |
---|---|---|
isNetwork |
Name | Type | Default value | Description |
---|---|---|---|
pon_Splitter.haltOn | int | 10 | |
epon_onu.onu_port.epon_mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_onu.onu_port.epon_mac.txQueueLimit | int | 2 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" The 2nd frame is used in case of changing registers with MPCP ... sometimes 1 is already transmitted and the next MPCP decides to transmitt again with the new times. |
epon_onu.onu_port.epon_mac.queueModule | string | "" |
name of optional external queue module |
epon_onu.onu_port.epon_mac.mtu | int | 1500 | |
epon_onu.onu_port.onu_Q_mgmt.regTimeOut | int | ||
epon_onu.onu_port.onu_Q_mgmt.queueLimit | int | ||
epon_onu.onu_port.onu_Q_mgmt.statsGranularity | double | ||
epon_onu.epon_ONU_relay.addressTableFile | string | ||
epon_onu.epon_ONU_relay.addressTableSize | int | ||
epon_onu.epon_ONU_relay.agingTime | double | ||
epon_onu.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_onu.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
epon_onu.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
epon_onu.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
epon_onu.mac.queueModule | string | "" |
name of optional external queue module |
epon_onu.mac.mtu | int | 1500 | |
host1.cli.destAddress | string | "" |
destination MAC address, or module path name of destination station; empty means off |
host1.cli.startTime | double | this.waitTime |
time of sending the first request |
host1.cli.waitTime | double | uniform(0s,1s) |
interval between sending requests |
host1.cli.reqLength | int | 100B |
length of request packets |
host1.cli.respLength | int | 1KB |
length of response packets |
host1.mac.promiscuous | bool | false |
if true, all packets are received, otherwise only the ones with matching destination MAC address |
host1.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
host1.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
host1.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
host1.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
host1.mac.mtu | int | 1500 | |
epon_onu3.onu_port.epon_mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_onu3.onu_port.epon_mac.txQueueLimit | int | 2 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" The 2nd frame is used in case of changing registers with MPCP ... sometimes 1 is already transmitted and the next MPCP decides to transmitt again with the new times. |
epon_onu3.onu_port.epon_mac.queueModule | string | "" |
name of optional external queue module |
epon_onu3.onu_port.epon_mac.mtu | int | 1500 | |
epon_onu3.onu_port.onu_Q_mgmt.regTimeOut | int | ||
epon_onu3.onu_port.onu_Q_mgmt.queueLimit | int | ||
epon_onu3.onu_port.onu_Q_mgmt.statsGranularity | double | ||
epon_onu3.epon_ONU_relay.addressTableFile | string | ||
epon_onu3.epon_ONU_relay.addressTableSize | int | ||
epon_onu3.epon_ONU_relay.agingTime | double | ||
epon_onu3.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_onu3.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
epon_onu3.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
epon_onu3.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
epon_onu3.mac.queueModule | string | "" |
name of optional external queue module |
epon_onu3.mac.mtu | int | 1500 | |
epon_onu2.onu_port.epon_mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_onu2.onu_port.epon_mac.txQueueLimit | int | 2 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" The 2nd frame is used in case of changing registers with MPCP ... sometimes 1 is already transmitted and the next MPCP decides to transmitt again with the new times. |
epon_onu2.onu_port.epon_mac.queueModule | string | "" |
name of optional external queue module |
epon_onu2.onu_port.epon_mac.mtu | int | 1500 | |
epon_onu2.onu_port.onu_Q_mgmt.regTimeOut | int | ||
epon_onu2.onu_port.onu_Q_mgmt.queueLimit | int | ||
epon_onu2.onu_port.onu_Q_mgmt.statsGranularity | double | ||
epon_onu2.epon_ONU_relay.addressTableFile | string | ||
epon_onu2.epon_ONU_relay.addressTableSize | int | ||
epon_onu2.epon_ONU_relay.agingTime | double | ||
epon_onu2.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_onu2.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
epon_onu2.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
epon_onu2.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
epon_onu2.mac.queueModule | string | "" |
name of optional external queue module |
epon_onu2.mac.mtu | int | 1500 | |
host3.cli.destAddress | string | "" |
destination MAC address, or module path name of destination station; empty means off |
host3.cli.startTime | double | this.waitTime |
time of sending the first request |
host3.cli.waitTime | double | uniform(0s,1s) |
interval between sending requests |
host3.cli.reqLength | int | 100B |
length of request packets |
host3.cli.respLength | int | 1KB |
length of response packets |
host3.mac.promiscuous | bool | false |
if true, all packets are received, otherwise only the ones with matching destination MAC address |
host3.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
host3.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
host3.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
host3.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
host3.mac.mtu | int | 1500 | |
host4.cli.destAddress | string | "" |
destination MAC address, or module path name of destination station; empty means off |
host4.cli.startTime | double | this.waitTime |
time of sending the first request |
host4.cli.waitTime | double | uniform(0s,1s) |
interval between sending requests |
host4.cli.reqLength | int | 100B |
length of request packets |
host4.cli.respLength | int | 1KB |
length of response packets |
host4.mac.promiscuous | bool | false |
if true, all packets are received, otherwise only the ones with matching destination MAC address |
host4.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
host4.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
host4.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
host4.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
host4.mac.mtu | int | 1500 | |
host2.cli.destAddress | string | "" |
destination MAC address, or module path name of destination station; empty means off |
host2.cli.startTime | double | this.waitTime |
time of sending the first request |
host2.cli.waitTime | double | uniform(0s,1s) |
interval between sending requests |
host2.cli.reqLength | int | 100B |
length of request packets |
host2.cli.respLength | int | 1KB |
length of response packets |
host2.mac.promiscuous | bool | false |
if true, all packets are received, otherwise only the ones with matching destination MAC address |
host2.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
host2.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
host2.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
host2.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
host2.mac.mtu | int | 1500 | |
epon_olt.epon_OLT_relay.addressTableFile | string |
set to empty string if not used |
|
epon_olt.epon_OLT_relay.addressTableSize | int |
max size of address table |
|
epon_olt.epon_OLT_relay.agingTime | double |
max idle time for address table entries (when it expires, entry is removed from the table) |
|
epon_olt.mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_olt.mac.txrate | double | 100Mbps |
maximum data rate supported by this station (bit/s); actually chosen speed may be lower due to auto- configuration. 0 means fully auto-configured. |
epon_olt.mac.duplexEnabled | bool | true |
whether duplex mode can be enabled or not; whether MAC will actually use duplex mode depends on the result of the auto-configuration process (duplex is only possible with DTE-to-DTE connection). |
epon_olt.mac.txQueueLimit | int | 1000 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" |
epon_olt.mac.queueModule | string | "" |
name of optional external queue module |
epon_olt.mac.mtu | int | 1500 | |
epon_olt.olt_if.epon_mac.address | string | "auto" |
MAC address as hex string (12 hex digits), or "auto". "auto" values will be replaced by a generated MAC address in init stage 0. |
epon_olt.olt_if.epon_mac.txQueueLimit | int | 2 |
maximum number of frames queued up for transmission; additional frames are dropped. Only used if queueModule=="" The 2nd frame is used in case of changing registers with MPCP ... sometimes 1 is already transmitted and the next MPCP decides to transmitt again with the new times. |
epon_olt.olt_if.epon_mac.queueModule | string | "" |
name of optional external queue module |
epon_olt.olt_if.epon_mac.mtu | int | 1500 | |
epon_olt.olt_if.olt_Q_mgmt.slotLength | int | ||
epon_olt.olt_if.olt_Q_mgmt.slotNumber | int | ||
epon_olt.olt_if.olt_Q_mgmt.regTimeInt | int | ||
epon_olt.olt_if.olt_Q_mgmt.regAckTimeOut | int | ||
epon_olt.olt_if.olt_Q_mgmt.queueLimit | int | ||
epon_olt.olt_if.olt_Q_mgmt.datarateLimit | int |
Limit the assigned bandwidth to scale down the simulation |
|
serviceConfig.services | string | "DATA" |
Service Names (whatever you like here) |
serviceConfig.srvPrior | string | "1.0" |
Service priority. Total sum must be 1 |
serviceConfig.vlanMap | string | "0" |
Vlan map |
serviceConfig.msrPerFlow | string | "1000000" |
MSR per flow, default 1Mbps (-1 = Unlimited) |
serviceConfig.mrrPerFlow | string | "1000000" |
MRR per flow, default 1Mbps (-1 = Unlimited) |
network pon_srv { types: channel GFX extends DatarateChannel { datarate = 1Gbps; } submodules: pon_Splitter: PON_Splitter { @display("p=230,142"); } epon_onu: EPON_ONU { @display("p=432,66"); } host1: EtherHost { @display("p=538,66"); } epon_onu3: EPON_ONU { @display("p=432,185"); } epon_onu2: EPON_ONU { @display("p=432,123"); } host3: EtherHost { @display("p=538,130"); } host4: EtherHost { @display("p=538,192"); } host2: EtherHost { @display("p=86,72"); } epon_olt: EPON_OLT { @display("p=141,142"); } serviceConfig: ServiceConfig { @display("p=221,34"); } connections: // to splitter epon_olt.epon <--> GFX <--> pon_Splitter.portu; pon_Splitter.portg++ <--> GFX <--> epon_onu.epon; pon_Splitter.portg++ <--> GFX <--> epon_onu2.epon; pon_Splitter.portg++ <--> GFX <--> epon_onu3.epon; // Hosts epon_onu.ethg <--> DatarateChannel <--> host1.ethg; epon_onu2.ethg <--> DatarateChannel <--> host3.ethg; epon_onu3.ethg <--> DatarateChannel <--> host4.ethg; epon_olt.ethg <--> DatarateChannel <--> host2.ethg; }
